Galerie de photos de Dioné, satellite de la planète Saturne

PIA00028: Dione Mosaic	PIA01366: The Saturnian moon Dione
PIA01373: Saturn's satellite Dione	PIA02244: Dione
PIA02265: Dione - circular impact craters	PIA05418: Dark Side of Dione
PIA05436: Streaking Away from Dione	PIA06155: Dione and Saturn
PIA06156: Dione Close-up	$<h1>PIA06162: Dione's Surprise</h1><div class="PIA06162" lang="en" style="width:800px;text-align:left;margin:auto;background-color:#000;padding:10px;max-height:150px;overflow:auto;"><p>As it zoomed in on Saturn's moon Dione for a close flyby, the Cassini spacecraft captured a set of images of the icy moon which have been combined into a mosaic here to provide a stunningly detailed global view. </p><p>Five narrow angle frames comprise this view of the 'wispy terrain' on the anti-Saturn side of Dione. To the surprise of Cassini imaging scientists, the wispy terrain does not consist of thick ice deposits, but rather the bright ice cliffs created by tectonic fractures. The surface is also clearly very heavily cratered. The image scale is 0.9 kilometers (0.6 miles) per pixel; the phase angle is 34 degrees. </p><p>The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging team is based at the Space Science Institute, Boulder, Colo.</p><p>For more information, about the Cassini-Huygens mission visit, <a href="http://saturn.jpl.nasa.gov/">http://saturn.jpl.nasa.gov</a> and the Cassini imaging team home page, <a href="http://ciclops.org/">http://ciclops.org</a>.</p><br /><br /><a href="http://photojournal.jpl.nasa.gov/catalog/PIA06162" onclick="window.open(this.href); return false;" title="Voir l'image PIA06162: Dione's Surprise sur le site de la NASA">Voir l'image PIA06162: Dione's Surprise sur le site de la NASA.</a></div>$ PIA06162: Dione's Surprise
$<h1>PIA06163: Highest Resolution View of Dione</h1><div class="PIA06163" lang="en" style="width:800px;text-align:left;margin:auto;background-color:#000;padding:10px;max-height:150px;overflow:auto;"><p>This very detailed image taken during the Cassini spacecraft's closest approach to Saturn's moon Dione on Dec. 14, 2004 is centered on the wispy terrain of the moon. To the surprise of Cassini imaging scientists, the wispy terrain does not consist of thick ice deposits, but rather the bright ice cliffs created by tectonic fractures. </p><p>The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging team is based at the Space Science Institute, Boulder, Colo.</p><p>For more information, about the Cassini-Huygens mission visit, <a href="http://saturn.jpl.nasa.gov/">http://saturn.jpl.nasa.gov</a> and the Cassini imaging team home page, <a href="http://ciclops.org/">http://ciclops.org</a>.</p><br /><br /><a href="http://photojournal.jpl.nasa.gov/catalog/PIA06163" onclick="window.open(this.href); return false;" title="Voir l'image PIA06163: Highest Resolution View of Dione sur le site de la NASA">Voir l'image PIA06163: Highest Resolution View of Dione sur le site de la NASA.</a></div>$ PIA06163: Highest Resolution View of Dione	PIA06199: Cassini's Private Eclipse
PIA06499: Streaks on Dione	PIA06513: Dione's Streaky Side
PIA06528: Crisscrossing Streaks	PIA06542: Craters 'Twixt Day and Night
PIA06545: Powerful Impact	PIA06551: Pocked Moon
$<h1>PIA06561: Aeneas on the Edge</h1><div class="PIA06561" lang="en" style="width:324px;text-align:left;margin:auto;background-color:#000;padding:10px;max-height:150px;overflow:auto;"><p>This Cassini image of Saturn's moon Dione shows a nice view of the crater Aeneas on the terminator. The crater's diameter is approximately 175 kilometers (109 miles). The crater's central peak is about 3.5 kilometers (2 miles) high, which is comparable to the depth of the crater. This is principally the side of Dione that faces Saturn. Dione is 1,118 kilometers (695 miles) across.</p><p>The bright features on the moon's eastern limb are part of the fracture system seen at higher resolution in Cassini's first close approach to Dione on Dec. 14, 2004 (see <a href="/catalog/PIA06162">PIA06162</a>).</p><p>The image was taken in visible light with the Cassini spacecraft narrow angle camera on Dec. 10, 2004, at a distance of 2.7 million kilometers (1.7 million miles) from Dione and at a Sun-Dione-spacecraft, or phase, angle of 46 degrees. The image scale is about 16 kilometers (10 miles) per pixel. The image has been magnified by a factor of two and contrast enhanced to aid visibility.</p><p>The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging team is based at the Space Science Institute, Boulder, Colo.</p><p>For more information, about the Cassini-Huygens mission visit, <a href="http://saturn.jpl.nasa.gov/">http://saturn.jpl.nasa.gov</a> and the Cassini imaging team home page, <a href="http://ciclops.org/">http://ciclops.org</a>.</p><br /><br /><a href="http://photojournal.jpl.nasa.gov/catalog/PIA06561" onclick="window.open(this.href); return false;" title="Voir l'image PIA06561: Aeneas on the Edge sur le site de la NASA">Voir l'image PIA06561: Aeneas on the Edge sur le site de la NASA.</a></div>$ PIA06561: Aeneas on the Edge	PIA06607: Art and Science
$<h1>PIA06611: Far-off Fractures</h1><div class="PIA06611" lang="en" style="width:317px;text-align:left;margin:auto;background-color:#000;padding:10px;max-height:150px;overflow:auto;"><p>Wispy streaks curl over the horizon on Saturn's moon Dione, caught here in a distant view from Cassini. The streaks were first revealed by NASA's Voyager spacecraft and subsequently were shown by Cassini to be an immense system of linear fractures in the moon's surface. Dione is 1,118 kilometers (695 miles) across.</p><p>The image was taken with the Cassini spacecraft narrow-angle camera using a filter sensitive to wavelengths of ultraviolet light centered at 338 nanometers. The image was acquired on Feb. 18, 2005, at a distance of approximately 1.3 million kilometers (808,000 miles) from Dione and at a Sun-Dione-spacecraft, or phase, angle of 118 degrees. The image scale is 8 kilometers (5 miles) per pixel. </p><p>The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging team is based at the Space Science Institute, Boulder, Colo.</p><p>For more information about the Cassini-Huygens mission, visit <a href="http://saturn.jpl.nasa.gov">http://saturn.jpl.nasa.gov</a> and the Cassini imaging team home page, <a href="http://ciclops.org">http://ciclops.org</a>.</p><br /><br /><a href="http://photojournal.jpl.nasa.gov/catalog/PIA06611" onclick="window.open(this.href); return false;" title="Voir l'image PIA06611: Far-off Fractures sur le site de la NASA">Voir l'image PIA06611: Far-off Fractures sur le site de la NASA.</a></div>$ PIA06611: Far-off Fractures	PIA06626: Saturn-lit Surface
$<h1>PIA06634: Far off Cracks</h1><div class="PIA06634" lang="en" style="width:456px;text-align:left;margin:auto;background-color:#000;padding:10px;max-height:150px;overflow:auto;"><p>The distinctive, wispy system of fractures on the trailing hemisphere of Saturn's moon Dione shows a great deal of contrast in this ultraviolet view. Dione is 1,118 kilometers (695 miles) across.</p><p>North on Dione is up and tilted 30 degrees to the left.</p><p>The image was taken with the Cassini spacecraft narrow-angle camera on March 7, 2005, using a filter sensitive to wavelengths of ultraviolet light centered at 338 nanometers. The image was acquired at a distance of approximately 1.6 million kilometers (1 million miles) from Dione and at a Sun-Dione-spacecraft, or phase, angle of 50 degrees. Resolution in the original image was 9 kilometers (6 miles) per pixel. The image has been contrast-enhanced and magnified by a factor of two to aid visibility. </p><p>The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging team is based at the Space Science Institute, Boulder, Colo.</p><p>For more information about the Cassini-Huygens mission, visit <a href="http://saturn.jpl.nasa.gov">http://saturn.jpl.nasa.gov</a> and the Cassini imaging team home page, <a href="http://ciclops.org">http://ciclops.org</a>.</p><br /><br /><a href="http://photojournal.jpl.nasa.gov/catalog/PIA06634" onclick="window.open(this.href); return false;" title="Voir l'image PIA06634: Far off Cracks sur le site de la NASA">Voir l'image PIA06634: Far off Cracks sur le site de la NASA.</a></div>$ PIA06634: Far off Cracks	$<h1>PIA06638: Daybreak on Dione</h1><div class="PIA06638" lang="en" style="width:464px;text-align:left;margin:auto;background-color:#000;padding:10px;max-height:150px;overflow:auto;"><p>The Sun also rises on Saturn's moon Dione, seen in this image from Cassini. Wispy fractured terrain lies along the limb. Some details of the moon's topography can be noted along the terminator. Dione is 1,118 kilometers (695 miles) across.</p><p>This image is centered on territory at 310 degrees west longitude. The sunlit region in this view is on the trailing hemisphere on Dione. North is up and tilted 23 degrees to the left.</p><p>The image was taken with the Cassini spacecraft narrow-angle camera on March 12, 2005, through spectral filters sensitive to wavelengths of polarized green light. The view was acquired at a distance of approximately 1.8 million kilometers (1.1 million miles) from Dione and at a Sun-Dione-spacecraft, or phase, angle of 100 degrees. Resolution in the original image was 10 kilometers (7 miles) per pixel. The image has been contrast-enhanced and magnified by a factor of two to aid visibility. </p><p>The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging team is based at the Space Science Institute, Boulder, Colo.</p><p>For more information about the Cassini-Huygens mission, visit <a href="http://saturn.jpl.nasa.gov">http://saturn.jpl.nasa.gov</a> and the Cassini imaging team home page, <a href="http://ciclops.org">http://ciclops.org</a>.</p><br /><br /><a href="http://photojournal.jpl.nasa.gov/catalog/PIA06638" onclick="window.open(this.href); return false;" title="Voir l'image PIA06638: Daybreak on Dione sur le site de la NASA">Voir l'image PIA06638: Daybreak on Dione sur le site de la NASA.</a></div>$ PIA06638: Daybreak on Dione
PIA06652: F Ring Edges	$<h1>PIA07511: Dramatic Moon</h1><div class="PIA07511" lang="en" style="width:202px;text-align:left;margin:auto;background-color:#000;padding:10px;max-height:150px;overflow:auto;"><p>This unmagnified view of Saturn's moon Dione shows the moon's bright, wispy terrain, along with several large impact craters. Two of the craters have central peaks. Dione is 1,118 kilometers (695 miles) across.</p><p>North on Dione is up. This view shows principally the anti-Saturn hemisphere on Dione. It is clear why low-resolution NASA Voyager spacecraft images gave the impression that the Dionian wispy terrain might be bright ice deposits. High-resolution Cassini images have shown these to be complex systems of braided tectonic fractures.</p><p>The image was taken in visible light with the Cassini spacecraft narrow-angle camera on April 25, 2005, at a distance of approximately 2.8 million kilometers (1.7 million miles) from Dione and at a Sun-Dione-spacecraft, or phase, angle of 60 degrees. The image scale is 17 kilometers (11 miles) per pixel. </p><p>The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging team is based at the Space Science Institute, Boulder, Colo.</p><p>For more information about the Cassini-Huygens mission visit <a href="http://saturn.jpl.nasa.gov">http://saturn.jpl.nasa.gov</a>. For additional images visit the Cassini imaging team homepage <a href="http://ciclops.org">http://ciclops.org</a>.</p><br /><br /><a href="http://photojournal.jpl.nasa.gov/catalog/PIA07511" onclick="window.open(this.href); return false;" title="Voir l'image PIA07511: Dramatic Moon sur le site de la NASA">Voir l'image PIA07511: Dramatic Moon sur le site de la NASA.</a></div>$ PIA07511: Dramatic Moon
PIA07526: Soft Storms	$<h1>PIA07581: Older Southern Fractures?</h1><div class="PIA07581" lang="en" style="width:800px;text-align:left;margin:auto;background-color:#000;padding:10px;max-height:150px;overflow:auto;"><p>Dione's southern polar region (shown here) contains fractures whose softened appearance suggests that they have different ages than the bright braided fractures seen in the image to the north. This region is also notably brighter than the near equatorial terrain at the top of the image.</p><p>At the center, several of the bright, radial streaks mark a feature named Cassandra, which may be a rayed crater or a tectonic feature.</p><p>This view of Dione (1,118 kilometers, or 695 miles across) captures high southern latitudes on the moon's trailing hemisphere.</p><p>The image was taken in visible light with the Cassini spacecraft narrow-angle camera on Aug. 1, 2005, at a distance of approximately 269,000 kilometers (167,000 miles) from Dione and at a Sun-Dione-spacecraft, or phase, angle of 41 degrees. Image scale is 2 kilometers (1.2 miles) per pixel. </p><p>The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter was designed, developed and assembled at JPL. </p><p>For more information about the Cassini-Huygens mission visit <a href="http://saturn.jpl.nasa.gov">http://saturn.jpl.nasa.gov</a>. For additional images visit the Cassini imaging team homepage <a href="http://ciclops.org">http://ciclops.org</a>.</p><br /><br /><a href="http://photojournal.jpl.nasa.gov/catalog/PIA07581" onclick="window.open(this.href); return false;" title="Voir l'image PIA07581: Older Southern Fractures? sur le site de la NASA">Voir l'image PIA07581: Older Southern Fractures? sur le site de la NASA.</a></div>$ PIA07581: Older Southern Fractures?
$<h1>PIA07603: Virgil's Moon</h1><div class="PIA07603" lang="en" style="width:534px;text-align:left;margin:auto;background-color:#000;padding:10px;max-height:150px;overflow:auto;"><p>When naming features on other worlds, scientists like to follow themes, and Dione is no exception. Dione possesses numerous features with names from Virgil's "Aeneid." The prominent crater showing a central peak below the center is Dido, a 118-kilometer-wide (73-mile) crater named after the supposed founder of Carthage. The crater just above Dido is Antenor, an 82-kilometer-wide (51-mile) impact crater named after the nephew of Priam who founded the Italian city of Padua. At the upper right is the 97-kilometer-wide (60-mile) impact crater Turnus, which lies at the western end of Carthage Linea, a region of bright, fractured terrain. Dione is 1,118 kilometers (695 miles) across.</p><p>The sunlit terrain seen here shows some of the wispy markings on the moon's trailing hemisphere. Cassini revealed that these markings are actually a complex system of fractures.</p><p>North on Dione is up and rotated 25 degrees to the left.</p><p>The image was taken in visible light with the Cassini spacecraft narrow-angle camera on Aug. 25, 2005, at a distance of approximately 1.1 million kilometers (700,000 miles) from Dione and at a Sun-Dione-spacecraft, or phase, angle of 107 degrees. Resolution in the original image was 7 kilometers (4 miles) per pixel. The image has been magnified by a factor of two and contrast-enhanced to aid visibility. </p><p>The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging operations center is based at the Space Science Institute in Boulder, Colo.</p><p>For more information about the Cassini-Huygens mission visit <a href="http://saturn.jpl.nasa.gov">http://saturn.jpl.nasa.gov</a>. For additional images visit the Cassini imaging team homepage <a href="http://ciclops.org">http://ciclops.org</a>.</p><br /><br /><a href="http://photojournal.jpl.nasa.gov/catalog/PIA07603" onclick="window.open(this.href); return false;" title="Voir l'image PIA07603: Virgil's Moon sur le site de la NASA">Voir l'image PIA07603: Virgil's Moon sur le site de la NASA.</a></div>$ PIA07603: Virgil's Moon	PIA07618: Dione's Canyonlands

Page 1 de 4
